S1-Industrial Camera-Shenzhen Oseecam Technology Co., Ltd.

Product name: S1

◆ Adopting 8.29 million pixel Sony CMOS image sensor;
◆ Adopting a 1/2.8 inch image sensor;
◆ HDMI 3840 * 2160 30 frame/1080P 60 frame image output;
◆ USB 2.0 connection to computer driver free output 3840 * 2160 30 frame image output;
◆ 4K video recording;
◆ 4K photography;
◆ One click freeze/thaw function/same screen comparison;
◆ Remote focusing without shaking;
◆ Electronic zoom function;
◆ Supports manual/automatic exposure and exposure compensation value adjustment;
◆ Supports manual/automatic white balance, with adjustable red, green, and blue colors;
◆ Supports USB storage, with a maximum capacity of 64GB;
◆ Support remote control operation, taking photos without shaking, resulting in clearer images;
◆ Supports 8 menu languages (default English);
◆ Integrated design, built-in camera, light source, and microscope lens
◆ Support saving shutdown settings parameters;

Image display
Information

sensor	1/2.8-inch Sony 8.29 megapixel CMOS sensor
pixel size	1.45µm × 1.45µm
HDMI output	3840 * 2160 30 frames/1920 * 1080 60 frames
USB output	38402160/25601440/19201080/1280720/640480/424240/320*240 (MJPG)
field of view	100mm object distance	150mm object distance	200mm object distance	250mm object distance	300mm object distance
	25x14mm	38x21mm	50x28m	64x36mm	78*43mm
exposure	Auto/Manual
Exposure Compensation	support
white balance	Automatic/manual, adjustable R, G, B
storage	Maximum support for 64GB
INPUT VOLTAGE	DC 12V
light source	Built in 24 high brightness LED lights, adjustable brightness
lens	High definition microscope lens
menu language	English/Chinese/Arabic/Italian/Russian/Japanese/Spanish/French
remote control	support
Focusing method	Manual focusing (focusing knob, remote control)
net weight	200 grams
Product size	484860mm
